Waterproof Multistage Weight Sorting Machine for Food Industry | SWS-4523L2-C6
- Model
- SWS-4523L2-C6
Item specifics
- Weighting range
- 1-2000g
- Belt speed
- 5-90m/min
- Weighting accuracy
- ±0.3-2g
- Weighting section size
- L 450mm*W 230mm
- Applicable product size
- L≤300mm; W≤230mm
- Sorting port number
- 1-20 grade customizable
Review
Description
Detail Information
Waterproof Multistage Weight Sorting Machine for Food Industry | SWS-4523L2-C6
Introduction
The SWSD-4523L2 dual-layer weight sorting machine is designed for precise weight classification in the food industry, especially for seafood processing. Its upper-mounted motor creates a dual-layer layout, providing enhanced durability and IP65 waterproof protection for wet environments.
This fish weight sorting machine is also ideal for shrimp, poultry, and meat products. The conveyor belt weight sorting machine ensures smooth, hygienic operation with high accuracy. Fully customizable, the SWSD-4523L2 serves as a reliable waterproof multistage weight sorting machine, improving efficiency and consistency in modern food factories.
Waterproof Multistage Weight Sorting Machine for Food Industry | SWS-4523L2-C6
Features
Waterproof Multistage Weight Sorting Machine for Food Industry | SWS-4523L2-C6
Technical Parameters
| Product model | SWS-4523L2-C6 | |
| Weighting range | 1-2000g | |
Weighting section size | L 450mm*W 230mm | |
Belt speed | 5-90m/min | |
Air pressure interface | Φ8mm | |
Case material | 304 stainless steel | |
Display division | 0.1g | |
| Weighting accuracy | ±0.3-2g | |
| Applicable product size | L≤300mm; W≤230mm | |
Storage formula | 100 types | |
| Power supply | AC220V±10% | |
Air source | 0.5-0.8MPa | |
Data transmission | USB data export | |
Sorting port number | 1-20 grade customizable | |
Rejection mode | Air blowing, push rod, swing arm, drop, up and down flip, etc. (customizable) | |
Operation screen | 10-inch Weiluntong color touch screen | |
Control system | Samegram online weighing control system V1.0.5 | |
Other configurations | Meanwell power supply, Jingyan motor, Swiss PU food conveyor belt, NSK bearing, Mettler Toledo sensor | |
Available Rejection Systems for Waterproof Multistage Weight Sorting Machine
Up and Out Rejector for checkweigher and metal detector systems — stable, gentle, and precise for soft or thick products.
Fast swing arm works with checkweigher or metal detector systems to remove defective boxes and bags up to 1 kg.
Samegram’s Belt Drop rejector is a high speed rejector using pneumatic lift rods to gently remove thin bags and flat products.
The heavy-duty pusher rejector pair with checkweigher systems to deliver accurate, mid-speed removal of heavy, boxed items.
* The maximum checkweighing speed and accuracy may vary depending on the actual product being tested and the installation environment.
* When selecting the model, pay attention to the direction of product movement on the conveyor belt. For transparent or semi-transparent products, please contact our company.
* When selecting the model, pay attention to the direction of product movement on the conveyor belt. For transparent or semi-transparent products, please contact our company.
File Downloads
For more product related parameter files, please contact us.
