High-Speed Dynamic Weighing Scale for Parcel Logistics SC3-L-12080S60
- Model
- SC3-L-12080S60
Item specifics
- Weighting range
- 1-60kg
- Belt speed
- 5-120m/min
- Weighting accuracy
- 10-30g
- Weighting section size
- L 1200mm*W 800mm
- Applicable product size
- L≤800mm; W≤800mm
- Rejection mode
- Customized
Review
Description
Detail Information
High-Speed Dynamic Weighing Scale for Parcel Logistics SC3-L-12080S60
Introduction
The SC3-L-12080S60 is a high-speed dynamic weighing scale designed for logistics operations, capable of handling parcels from 1 to 60 kg with up to ±30g precision. Its wide belt and robust platform accommodate bulky or irregular packages while maintaining fast throughput of up to 120 m/min.
Primarily built for weighing parcel logistics, this system ensures accurate weigh out logistics for distribution centers, freight hubs, and industrial shipping lines. It integrates seamlessly with scanners and sorters, simplifying large-scale workflows and improving efficiency.
Although the standard configuration does not include an automated rejection system, the SC3-L-12080S60 can be customized as a checkweigher for applications that require automatic removal of overweight or underweight parcels, providing flexible solutions for diverse logistics needs.
High-Speed Dynamic Weighing Scale for Parcel Logistics SC3-L-12080S60 Features
High-Speed Dynamic Weighing Scale for Parcel Logistics SC3-L-12080S60
Technical Parameters
| Product model | SC3-L-12080S60 | |
| Weighting range | 1-60kg | |
Weighting section size | L 1200mm*W 800mm | |
Belt speed | 5-120m/min | |
Case material | Carbon steel spray painting | |
Display division | 1g | |
| Weighting accuracy | 10-30g | |
| Applicable product size | L≤800mm; W≤800mm | |
Storage formula | 1 type | |
| Power supply | AC220V±10% | |
Data transmission | USB data export | |
Sorting section | Standard 1 section | |
Rejection mode | Push rod type, lever type, balance wheel optional | |
| Optional function | Real-time printing, code reading and sorting, online code spraying, online code reading, online labeling | |
Operation screen | 7-inch Kunluntong color touch screen | |
Control system | Samegram online weighing control system V1.0.5 | |
Other configurations | Meanwell power supply, Jingyan motor, Swiss PU food conveyor belt, NSK bearing, Mettler Toledo sensor | |
* The maximum checkweighing speed and accuracy may vary depending on the actual product being tested and the installation environment.
* When selecting the model, pay attention to the direction of product movement on the conveyor belt. For transparent or semi-transparent products, please contact our company.
* When selecting the model, pay attention to the direction of product movement on the conveyor belt. For transparent or semi-transparent products, please contact our company.
File Downloads
For more product related parameter files, please contact us.
